TDK High Voltage-Contactors are designed with excellent extinguishing characteristics and can be used bipolar for charging and discharging. It is further available as a dual-coil non-bipolar version for increased load-cycle performance.
HVC series (ordering code B88269X***) meet the requirements for High-Voltage DC emergency disconnection applications in electric cars, trucks, busses and DC fast chargers.
Features
- high current capability of up to 500 A
- high voltage capability of up to 1200 V
- bipolar design for charging and discharging
- dual-coil non-bipolar design for coil energy saving and increased load-cycle performance
- hermetically sealed and high-speed arc extinguishing
- long life-time due to excellent extinguish characteristics
- optional detection of switching status using contactless auxiliary contacts
- TDK testing laboratory available
- TDK has advanced know-how based on 80 years gas tube technology experience
- UL 60947-4-1 approved
- AEC-Q200 qualified
- local and worldwide engineering support
Applications
- Battery management systems for electric vehicles
- DC Charging stations for e-mobility applications
- Photovoltaic and energy storage systems - using Lithium Ion battery >400 V
- Uninterruptable power supplies using high-voltage batteries
